With our Longspan shelving's modular design, and fast and easy assembly you can achieve the maximum possible storage capacity, regardless of the space you have available.

The Longspan Shelving system allows for the easy adjustment of storage heights and configurations as your requirements change; providing a system that moves and changes with you.

Longspan is equally suited for warehouse and office environments; easily configurable for a number of different applications. From low level hand-loaded shelving, to high-rise systems.

Incorporating varying frame and beam sizes, customising the system for your exact needs is really straightforward. Medium- and Longspan bays can be combined in the same rack, and a bolt-free, lock-in system ensures support beams remain in position. Longspan frames and beams are powder-coated anthracite and grey white.

Our Longspan shelving has been designed and tested to comply with the recommendations of the FEM Shelving Design Code 10.2.06.

Frame height
From 2m – 5m

Frame depths
0.45m / 0.6m / 0.75m / 0.8m / 0.9m / 1.0m / 1.2m

Beams are available in two weight duties:

  • 60mm high standard duty beam (1012mm / 1212mm / 1512mm / 1812mm / 2012mm / 2412mm)
  • 80mm high heavy duty beam (2012mm / 2412mm / 2712mm / 3012mm)

Steel shelf panels are available for the full range of frame widths and beam depths. Chipboard shelf panels are also available.


  • Bay loads up to 6,900kg
  • Shelf loads (per level) from 400kg – 900kg
